D-Link Gigabit PoE+ Smart Switch, 28 Port (DGS-1210-28P/E)

Home

Return goods

Finansing

Stores

Information

B2B sales

TEL. +45 7442 1078 (WEEKDAYS 9-17)

FAST WORLDWIDE DELIVERY

PRICE PROTECTION

30 DAYS RETURN POLICY

Managed Gigabit PoE switch with 24 PoE ports, 4 RJ45/SFP combo ports, 56 Gbit/s switching capacity, VLAN, QoS and advanced network management

Product no:

388 EUR /pc.

Add to cart

AV-CONNECTION

Fast worldwide delivery

+25 years of experience

30 days return policy

5-star customer service

Price protection

Highlights:

• 24 Gigabit Ethernet ports with PoE
• 4 Gigabit RJ45/SFP combo ports
• Supports IEEE 802.3af PoE and IEEE 802.3at PoE+
• 56 Gbit/s switching capacity
• Managed Layer 2 switch with VLAN, QoS and link aggregation
• Security features including ACL, MAC filtering and SSH/SSL
• Supports jumbo frames up to 9216 bytes
• 1U design for rack mounting

Managed Gigabit switch with PoE:

The D-Link DGS-1210-28P/E is a managed Layer 2 network switch with 24 Gigabit Ethernet ports, combining data connectivity and Power over Ethernet in the same network installation. PoE enables both network connectivity and power to be delivered through the Ethernet cable to compatible devices, reducing the need for separate power connections at each device.

The switch supports IEEE 802.3af and IEEE 802.3at. Ports 1-4 can deliver up to 30 W per port via 802.3at PoE+, while ports 5-24 support up to 15.4 W per port via 802.3af PoE. This makes the switch suitable for network installations where PoE-compatible devices need to be connected to a central switch. The Gigabit ports support auto-negotiation and Auto MDI/MDIX, while IEEE 802.3x flow control helps manage data transmission.

Flexible uplinks and high switching capacity:

In addition to the 24 Gigabit PoE ports, the DGS-1210-28P/E features 4 Gigabit RJ45/SFP combo ports. The combo ports provide a choice between copper-based Gigabit Ethernet and compatible SFP connections, allowing the switch to accommodate different network topologies and connection types. SFP support covers Gigabit connections, while the switch provides a total switching capacity of 56 Gbit/s.

The MAC address table supports up to 16,000 entries, and jumbo frames of up to 9216 bytes are supported. Link aggregation enables multiple connections to be combined logically, while Spanning Tree Protocol helps manage redundant connections and prevent network loops. The switch also supports full duplex as well as half duplex at applicable Ethernet speeds.

VLAN, QoS and network security:

As a managed switch, the DGS-1210-28P/E provides features for network segmentation, traffic management and administration. Up to 4094 VLANs are supported, while Quality of Service with 8 queues enables different types of network traffic to be prioritised. Port mirroring can be used for monitoring and troubleshooting, while IGMP snooping supports efficient handling of multicast traffic.

Security features include Access Control Lists and MAC address filtering, which can be used to control network access. SSH/SSL support enables protected management, while DHCP functionality includes both DHCP client and DHCP server. The combination of Layer 2 management, VLAN, QoS, link aggregation and access control provides extensive options for structuring and managing a wired network.

Ready for rack installation:

The switch has a 1U form factor and can be rack mounted, making it suitable for central network installations alongside other rack-mounted equipment. Active cooling is provided by three fans. Product dimensions are 4.4 x 25 x 44 cm (H x W x L), and the net weight is 4.41 kg.

The DGS-1210-28P/E is specified for operation at temperatures from -5 to 50 °C and relative humidity from 0-95%. It combines 24 PoE ports, flexible Gigabit combo ports and managed network functionality in a compact 1U format.

Specifications:

• Switch type: Managed Layer 2
• 24 x 10/100/1000BASE-T Gigabit Ethernet ports with PoE
• 4 x Gigabit RJ45/SFP combo ports
• PoE standards: IEEE 802.3af and IEEE 802.3at
• Ports 1-4: up to 30 W per port via IEEE 802.3at
• Ports 5-24: up to 15.4 W per port via IEEE 802.3af
• Switching capacity: 56 Gbit/s
• MAC address table: 16,000 entries
• VLANs: up to 4094
• QoS: 8 queues
• Jumbo frames: up to 9216 bytes
• Network standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u and IEEE 802.3x
• Supports link aggregation, port mirroring and Spanning Tree Protocol
• Supports IGMP snooping
• Security: ACL, MAC address filtering and SSH/SSL
• DHCP functions: DHCP client and DHCP server
• Duplex: half/full duplex at 10/100 Mbit/s and full duplex at Gigabit
• Auto-negotiation and Auto MDI/MDIX
• Form factor: 1U, rack mountable
• Cooling: 3 fans
• Typical power consumption: 238.4 W
• Operating temperature: -5 to 50 °C
• Storage temperature: -20 to 70 °C
• Relative humidity during operation and storage: 0-95%
• Dimensions: 4.4 x 25 x 44 cm (H x W x L)
• Weight: 4.41 kg

Product reviews and links

D-Link DGS-1210-28P/E spec sheet (EN)

DLK-DGS-1210-28PE: D-Link Gigabit PoE+ Smart Switch, 28 Port (DGS-1210-28P/E)
