Highlights:• Integrated 2-channel Dante® module for digital audio streaming• 1 x 120 W amplifier with silent, fanless operation • 3 balanced mic/line inputs and 1 aux input • Priority and automatic talkover on Mic 1 • Supports both 230 V mains and 24 V emergency power supply • Insert connection for effects, EQs and feedback controllers • Compact 2 RU rack design with removable brackets • Ideal for professional integration into Dante® networks Digital Dante® Functionality With Analog Flexibility:With the addition of an integrated 2-channel Dante® module, the PA-900 and AKB-160 receive a significant upgrade that opens the door to digital audio distribution. Through an RJ45 connection, the unit can receive either one stereo signal or two mono signals, which are then converted into analog audio and amplified. This allows you to seamlessly connect existing analog speaker systems to a modern Dante® network—without compromising on sound quality or system stability. Perfect for installations in offices, schools, conference centers, and retail environments.Powerful and Silent Performance:This amplifier delivers 120 W RMS and a peak output power of up to 160 W. The compact chassis is designed for completely silent operation using a fanless cooling concept, making it a great choice for quiet environments such as meeting rooms, libraries, and houses of worship. The three balanced XLR inputs ensure professional-grade connectivity for microphones and other sources, while Mic 1 includes a priority circuit and talkover for clear speech transmission. The aux input allows easy connection of media players and external devices.Full Control and Versatile Features:With independent input and output level controls, 2-band tone control, and insert facilities, this amplifier offers outstanding flexibility. Each microphone input supports 20 V phantom power that can be individually activated, making the unit compatible with a wide range of microphones. Speaker connections are provided via screw terminals, and a separate line output allows for signal forwarding. The ability to operate on either 230 V mains or 24 V DC ensures reliable performance in both standard and emergency scenarios. Removable rack ears make it easy to install in AV racks and equipment cabinets.Specifications:• Output power: 1 x 120 W RMS• Power at 4 Ohm / 70 V / 100 V: 120 W • Peak output power: 160 W • Inputs: 3 x XLR (mic/line), 1 x RCA L/R (aux), 1 x RJ45 (Dante®) • Frequency response: 50 – 15,000 Hz • S/N ratio: > 80 dB • THD: < 0.5 % • Tone control: ±10 dB (bass/100 Hz, treble/10 kHz) • Phantom power: 20 V per mic input • Power supply: 230 V~ / 50 Hz / 300 VA or 24 V DC / 9 A • Operating temperature: 0 – 40 °C • Dimensions (W x H x D): 482 x 88 x 275 mm • Rack units: 2 RU • Weight: 10.53 kg
